Skunk2 Ultra Series B Series Race Centerfeed Complete Intake Manifold
Skunk2 Ultra Series B Series Race Centerfeed Complete Intake Manifold
A$1,880.52
Special Order. Contact for ETA.
This item is out of stock in our warehouse and partner distribution centres. In some cases, this may be due to not having live inventory feeds available for all suppliers. Please contact us before ordering if you need to meet a specific deadline.
We accept
Description
Skunk2 Racing is proud to announce the next generation of high performance intake manifolds! The much anticipated Ultra Race Centerfeed Intake Manifold is the result of years worth of R&D and building upon the performance legacy of our Pro Series Intake Manifold. Using the latest in CFD (Computational Fluid Dynamics) software; Skunk2 Racing has created a three-piece modular design that allows for easy disassembly, porting, and plenum volume changes through the use of a removable plenum and optional plenum spacers. The result is a design that is less restrictive, yielding both torque and power gains well over many of the competitors.
Product Overview
The much anticipated Ultra Race Intake Manifold is the result of years worth of R&D and building upon the performance legacy of our Pro Series Intake Manifold. Using the latest in CFD (Computational Fluid Dynamics) software; Skunk2 Racing has created a three-piece modular design that allows for easy disassembly, porting, and plenum volume changes through the use of a removable plenum and optional plenum spacers. The result is a design that is less restrictive, yielding both torque and power gains well over many of the competitors.
*FEATURES:*
* Modular 3pc. Design w/ Removable Plenum
* 3.5L Plenum Volume**
* 90mm Throttle Body Flange - Std. 5.0L Ford Pattern
* Tapered Hi-Velocity Runners
* Raised Velocity Stacks
* Generously Cast Runner Walls for Porting
* Provisions Secondary Fuel Rail & Injectors
* Hi-Grade Mounting Hardware
* Thermal Gasket Included
* Fits MOST Popular Chassis Configurations - Not Just Race Cars (See Notes)
Features and Benefits
- Modular 3pc. Design w/Removable Plenum
- 5.0L Plenum Volume
- 90mm Throttle Body Flange - Std. 5.0L Ford Pattern
- 6.0 in. Tapered Hi-Velocity Runners
- Raised 87mm Velocity Stacks
- Provisions Secondary Fuel Rail And Injectors
- Universal Mounting Flange Fits All B VTEC Cylinder Heads
- 3 in. x 1/8 in. NPT And 3 in. x 1/4 in. NPT Accessory Ports
- Hi-Grade Mounting Hardware
- Thermal Gasket Included
- Fits Most Popular Chassis Configurations
- US Patent No. D673977
Product Details
| Color: | Silver |
|---|---|
| Cylinder Head Type: | Ford 3V |
| Description: | Ultra Series Race Centerfeed Intake Manifold |
| Emission: | N/A |
| Engine Make/Size: | Honda/Acura B18C |
| Number of Carbs: | None; For Fuel Injection |
| Part Number: | skk307-05-9080 |
| Position: | Upper |
| RPM Range: | N/A |
| Usage: | Racing |
| WARNING CA Proposition 65 Message: | WARNING: This product can expose you to chemicals including lead; which is known to the State of California to cause cancer. For more information; go to www.P65Warnings.ca.gov. |
| WARNING CA Proposition 65: | Yes |
Part Type
Intake Manifolds, Fuel Injected
Features
- 3 in. x 1/8 in. NPT And 3 in. x 1/4 in. NPT Accessory Ports
- 5.0L Plenum Volume
- 6.0 in. Tapered Hi-Velocity Runners
- 90mm Throttle Body Flange - Std. 5.0L Ford Pattern
- Fits Most Popular Chassis Configurations
- Hi-Grade Mounting Hardware
- Modular 3pc. Design w/Removable Plenum
- Provisions Secondary Fuel Rail And Injectors
- Raised 87mm Velocity Stacks
- Thermal Gasket Included
- Universal Mounting Flange Fits All B VTEC Cylinder Heads
- US Patent No. D673977
Specifications
- Product Attributes - Brand
- Skunk 2
- Product Attributes - Manufacturer's Part Number
- 307-05-9080
- Product Attributes - Part Type
- Intake Manifolds, Fuel Injected
- Product Attributes - Product Line
- Skunk2 Racing Ultra Race Intake Manifolds
- Product Attributes - UPC
- 841509101245
- Product Attributes - Cylinder Head Configuration
- Stock
- Product Attributes - Fuel Injection Style
- Multi-port
- Product Attributes - Intake Section Included
- Complete
- Product Attributes - Throttle Body Bore Size
- 90mm
- Product Attributes - Engine Block Deck Height
- Standard deck
- Product Attributes - Injectors Included
- No
- Product Attributes - Multi-Port Fuel Rails Included
- No
- Product Attributes - EGR
- No
- Product Attributes - Aftermarket Fuel Rail Required
- No
- Product Attributes - Throttle Body Included
- No
- Product Attributes - Supplemental Bosses Cast-In
- Yes
- Product Attributes - Supplemental Bosses Machined
- Yes
- Product Attributes - Supplemental Boss Quantity
- Four
- Product Attributes - Runners Included
- Yes
- Product Attributes - Runners Removable
- Yes
- Product Attributes - Plenum Material
- Aluminum
- Product Attributes - Plenum Finish
- Natural
- Product Attributes - Base Material
- Aluminum
- Product Attributes - Base Color
- Natural
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
Reference Information
| Brand Name/s | Skunk2 Racing |
|---|---|
| StreetFX SKU | skk307-05-9080 |
| SFX Item ID | 4442566 |
| Supplier Item Code | 4442566 |
| Manufacturer SKU | 307-05-9080 |
| Manufacturer UPC | 841509101245 |
| Alternative References | skunk2, SK2-307-05-9080 |
