MSD Pro-Billet Front Drive Distributors 85201 Distributor, Drive, Hall Effect, Mechanical, Belt Driven, Male HEI Cap, Billet Aluminum, Red Anodized/Natural, Chevy, Big Block, Each
MSD Pro-Billet Front Drive Distributors 85201 Distributor, Drive, Hall Effect, Mechanical, Belt Driven, Male HEI Cap, Billet Aluminum, Red Anodized/Natural, Chevy, Big Block, Each
A$2,597.31
BACKORDER
This item will be special ordered in for you. Contact us prior to purchase if you require an ETA.
We accept
Description
MSD's Pro-Billet front drive distributors are the solution for race engines that don't have room for a standard distributor, due to firewall clearance or intake combinations. They're run by a wide 9mm belt that is driven by a pulley installed on the camshaft. The belt is wider than any other drive assembly for increased strength and durability. The distributor head is CNC-machined from billet aluminum and is secured to a stout billet aluminum bracket for strength. This system is an extremely accurate way to distribute the spark energy in harsh racing conditions. The distributors have a built-in belt adjustment feature for easy tension adjustments, and a band clamp mount for easy rotor phasing adjustments. They include MSD's Pro-Cap that is injection-molded from Dupont Rynite material for high dielectric strength, and the five in. diameter ensures accurate spark delivery. The distributors are supplied with mounting bolts, a cam pulley, hardware, and a drive belt. They must be used with a Jesel camshaft belt drive kit and an MSD Flying Magnet crank trigger.
Part Type
Distributors
Specifications
- Product Attributes - Brand
- MSD Ignition
- Product Attributes - Manufacturer's Part Number
- 85201
- Product Attributes - Part Type
- Distributors
- Product Attributes - Product Line
- MSD Pro-Billet Front Drive Distributors
- Product Attributes - UPC
- 085132000074
- Product Attributes - Distributor Cap Included
- Yes
- Product Attributes - Distributor Cap Style
- Male/HEI
- Product Attributes - Distributor Cap Type
- Large cap
- Product Attributes - Ignition Coil Included
- No
- Product Attributes - Ignition Module Included
- No
- Product Attributes - Computer-Controlled Compatible
- Yes
- Product Attributes - Trigger Style
- Hall effect
- Product Attributes - Advance Type
- Mechanical
- Product Attributes - Ignition Box Required
- Yes
- Product Attributes - Mechanical Tach Drive
- No
- Product Attributes - Slip Collar
- No
- Product Attributes - Distributor Gear Rotation
- Standard
- Product Attributes - Distributor Cap Color
- Red
- Product Attributes - Housing Material
- Aluminum
- Product Attributes - Housing Finish
- Natural
- Product Attributes - Marine Use
- No
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
Reference Information
| Brand Name/s | Msd Ignition |
|---|---|
| StreetFX SKU | msd85201 |
| SFX Item ID | 4973759 |
| Supplier Item Code | 4973759 |
| Manufacturer SKU | 85201 |
| Manufacturer UPC | 85132000074 |
