Manley Platinum Series Pistons 566205PC-1 Piston, Turbo Tuff, Forged, Dish, 4.005 in. Bore, Passenger Side, LS, Each

SKU: MAN566205PC-1

Pistons

Manley Platinum Series Pistons 566205PC-1 Piston, Turbo Tuff, Forged, Dish, 4.005 in. Bore, Passenger Side, LS, Each

Manley Performance

Manley Performance

Manley Platinum Series Pistons 566205PC-1 Piston, Turbo Tuff, Forged, Dish, 4.005 in. Bore, Passenger Side, LS, Each

SKU: MAN566205PC-1

Pistons
A$357.85
BACKORDER This item will be special ordered in for you. Contact us prior to purchase if you require an ETA.
View cart 0
We accept
American Express
Mastercard
Visa
PayPal Checkout
Direct Deposit
Afterpay
Apple Pay
Google Pay
Zip Pay

Description

Manley Platinum Series pistons are designed to provide trouble-free installation, excellent reliability, and maximum horsepower for your application. Available in 2618 and 4032 forgings, they provide the optimum balance between strength and weight, with no grain-interrupting internal milling. The Platinum Series pistons' 2618 alloy offers maximum high-temperature strength and fatigue resistance, while the 4032 alloy is ideal for moderate-horsepower street applications. Order the style and size pistons designed for your vehicle and engine.

Part Type

Pistons

Data: v4.2 - Upd: 2026-10-14 10:05:38

Specifications

Product Attributes - Brand
Manley
Product Attributes - Manufacturer's Part Number
566205PC-1
Product Attributes - Part Type
Pistons
Product Attributes - Product Line
Manley Platinum Series Pistons
Product Attributes - UPC
807298109404
Product Attributes - Piston Rings Included
No
Product Attributes - Bore (in.)
4.005 in.
Product Attributes - Bore (mm)
101.730mm
Product Attributes - Stroke
4.000 in.
Product Attributes - Engine Stroke Type
Stroked
Product Attributes - Rod Length
6.125 in.
Product Attributes - Piston Style
Dish, with no valve reliefs
Product Attributes - Piston Material
Forged aluminum
Product Attributes - Compression Height (in.)
1.115 in.
Product Attributes - Piston Head Volume (cc)
-18.00cc
Product Attributes - Wrist Pin Style
Press-fit or floating
Product Attributes - Wrist Pin Retainers Included
Yes
Product Attributes - Wrist Pin Included
Yes
Product Attributes - Pin Diameter (in.)
0.927 in.
Product Attributes - Piston Ring Thickness
1.50mm x 1.50mm x 3.00mm
Product Attributes - File Fit
No
Product Attributes - Gapless
No
Product Attributes - Remanufactured
No
Product Attributes - Quantity
Sold individually.
Product Attributes - Notes
Passenger side cylinder bank only. Coated piston skirt. Will fit LS1, LS2, LS3, LS6 and L92 valve pocket cylinder heads.

Reference Information

Brand Name/s Manley Performance
StreetFX SKU man566205PC-1
SFX Item ID 4932963
Supplier Item Code 4932963
Manufacturer SKU 566205PC-1
Manufacturer UPC 807298109404

Compatibility

Application Data
  • MakeCHEVROLET
    Beginning Year1999
    Ending Year2019
    Engine TypeV8
    Engine FamilyChevy small block Gen III/IV (LS-based engines)
    Engine Size6.0L/364
    Application NotesPassenger side cylinder bank only. Coated piston skirt. Will fit LS1, LS2, LS3, LS6 and L92 valve pocket cylinder heads.
