JE Pistons 302 Heavy-Duty Inverted Dome Top 314511R Pistons, Single - 302/351 SBF DISH
JE Pistons 302 Heavy-Duty Inverted Dome Top 314511R Pistons, Single - 302/351 SBF DISH
A$505.15
BACKORDER
This item will be special ordered in for you. Contact us prior to purchase if you require an ETA.
We accept
Description
JE Pistons has applied over 75 years of experience to its wide range of premium forged pistons for European, import, and sport compact applications, and they have been performance-proven in victory lane time and time again.
JE Pistons 302 heavy-duty inverted dome top pistons are single replacements forged from 2618 aluminum and utilize a dedicated Forged Side Relief (FSR) design that minimizes friction and power loss with a reduced skirt width, and additional weight is saved with a shorter wrist pin. Equip your engine with the best in forged pistons—JE Pistons.
Part Type
Pistons
Specifications
- Product Attributes - Brand
- JE Pistons
- Product Attributes - Manufacturer's Part Number
- 314511R
- Product Attributes - Part Type
- Pistons
- Product Attributes - Product Line
- JE Pistons 302 Heavy-Duty Inverted Dome Top Pistons
- Product Attributes - UPC
- 193564186188
- Product Attributes - Piston Rings Included
- No
- Product Attributes - Bore (in.)
- 4.125 in.
- Product Attributes - Bore (mm)
- 104.775mm
- Product Attributes - Stroke
- 3.400 in.
- Product Attributes - Engine Stroke Type
- Stroked
- Product Attributes - Actual Engine Displacement
- 6.0L/364
- Product Attributes - Rod Length
- 5.400 in.
- Product Attributes - Piston Style
- Dish, with two valve reliefs
- Product Attributes - Piston Material
- Forged aluminum
- Product Attributes - Compression Height (in.)
- 1.100 in.
- Product Attributes - Piston Head Volume (cc)
- -14.00cc
- Product Attributes - Wrist Pin Style
- Press-fit or floating
- Product Attributes - Wrist Pin Retainers Included
- Yes
- Product Attributes - Wrist Pin Included
- Yes
- Product Attributes - Pin Diameter (in.)
- 0.972 in.
- Product Attributes - Piston Ring Thickness
- 0.064 in. x 0.064 in. x 0.188 in.
- Product Attributes - File Fit
- No
- Product Attributes - Gapless
- No
- Product Attributes - Top Ring Thickness
- 0.064 in.
- Product Attributes - Top Ring Material
- Ductile iron
- Product Attributes - Top Ring Facing Material
- Plasma-moly
- Product Attributes - Second Ring Thickness
- 0.064 in.
- Product Attributes - Second Ring Material
- Ductile iron
- Product Attributes - Second Ring Facing Material
- Phosphate coated
- Product Attributes - Oil Ring Thickness
- 0.118 in.
- Product Attributes - Oil Ring Material
- Carbon steel
- Product Attributes - Oil Ring Tension
- Low
- Product Attributes - Remanufactured
- No
- Product Attributes - Quantity
- Sold individually.
- Product Attributes - Notes
- Fits right side exhaust valve orientation, works with turbocharger and nitrous.
Reference Information
| Brand Name/s | JE Pistons |
|---|---|
| StreetFX SKU | jep314511R |
| SFX Item ID | 4804559 |
| Supplier Item Code | 4804559 |
| Manufacturer SKU | 314511R |
| Manufacturer UPC | 193564186188 |
