Description

These upper control arms feature ICON's patented Delta Joint. The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

Product Overview

These upper control arms feature ICON's patented Delta Joint. The Delta Joint is a heavy-duty high angle ball joint that combines the durability of a ball joint with the performance characteristics of a traditional uniball. While the industry standard uniball does a great job of allowing the control arms of a vehicle to articulate with little bind, they do have an inherent weakness that leaves more to be desired when used in a daily driven application - exposure to the elements. The Delta Joint features a zinc plated housing providing the first layer of corrosion resistance, while a tough grease seal keeps potentially harmful elements out of the inner workings of the joint. Metal on metal construction and a greaseable design increase the longevity of the Delta Joint while at the same time allowing for noise-free operation. What makes the Delta Joint unique is that it brings the best of both worlds to ICON upper control arms with features that make it more robust than a uniball, and at the same time capable of greater angularity than a typical ball joint.

Features and Benefits

• O-ring Sealed Delta Joint Cover Cap For Additional Protection From The Elements
• ICON Delta Joint
• CNC Machined 6061 Billet Aluminum Construction
• Quality PTFE-lined ¾” FK Rod Ends
• On-Vehicle Adjustable For Quick And Precise Alignment
• Caster and Camber Adjustability Allows For Fine Tuning Of Vehicle Handling
• Matte Anodized Finish Provides Exceptional Corrosion Resistance

Product Details

AAP_UDA_12:	EA
AAP_UDA_22:	1
AAP_UDA_4:	55
Add-On Part:	191013 - NIPPLE GREASING ADAPTER KIT
Adjustable Control Arm:	yes
Adjustable:	Yes
Ball Joint Included:	Yes
Ball Joint Mounting Type:	Press In
Ball Joint Stud Type:	Threaded
Bushing Material:	Rod End Bearing
Bushings Included:	Yes
California Prop 65 Warning:	Yes
California Proposition 65:	WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Color:	Gray
Construction:	Billet
Control Arm Color:	Gray
Control Arm Construction:	Billet
Control Arm Material:	Aluminum
Description:	07-21 TUNDRA BILLET UCA DJ KIT
Finish:	Anodized
Grade Type:	Performance
Grease Fitting Included:	yes
Material:	Aluminum
Mounting Hardware Included:	Yes
OEM Wheels & Tires Fitment:	Yes
Part Number:	ico58560DJ
Pre-Greased:	No
Quantity:	Pair
Recommended Aftermarket Tires:	35" x 12.50" (Larger tires may fit but fender trimming and modifications will be required)
Recommended Aftermarket Wheels:	ICON Alloys | 20x9" w/ 6” Backspace / 25mm Offset
Reinforced:	Yes
Service Parts:	614519 - DELTA JOINT INSTALL PRESS ADAPTER TUBE
Suspension Grade Type:	Performance
Suspension Type:	Spring
Title:	ICON 2007-2021 Toyota Tundra/2008-2022 Toyota Sequoia, Billet Front Upper Control Arm w/ Delta Joint Kit

Kit Options

This item is available as a full kit.
Select a kit option in the following table if you are looking for this item in a bundle form with all associated components.

Kit option/s:

Thumb	SKU	Kit Title
	icoK53167	ICON 2007+ Toyota Tundra 1.63-3in Stage 3 3.0 Suspension System (2x ico158509, 1x ico52050, 1x ico56108, 1x ico58560DJ, 1x ico58755, 1x ico59923P)
	icoK53166	ICON 2007+ Toyota Tundra 1.63-3in Stage 2 3.0 Suspension System (2x ico158509, 1x ico52050, 1x ico56108, 1x ico58560DJ, 1x ico58755, 1x ico57823CP)
	icoK53030	ICON 2007+ Toyota Tundra 1-3in Stage 10 Suspension System w/Billet Uca (2x ico158509, 1x ico52050, 1x ico58560DJ, 1x ico59923P, 1x ico58750C)
	icoK53028	ICON 2007+ Toyota Tundra 1-3in Stage 8 Suspension System w/Billet Uca (2x ico158509, 1x ico52050, 1x ico58560DJ, 1x ico57823P, 1x ico58750)
	icoK53029	ICON 2007+ Toyota Tundra 1-3in Stage 9 Suspension System w/Billet Uca (2x ico158509, 1x ico52050, 1x ico58560DJ, 1x ico57823CP, 1x ico58750C)
	icoK53165	ICON 2007+ Toyota Tundra 1.63-3in Stage 1 3.0 Suspension System (2x ico158509, 1x ico52050, 1x ico58560DJ, 1x ico58755, 1x ico57823CP)
	icoK53027	ICON 2007+ Toyota Tundra 1-3in Stage 7 Suspension System w/Billet Uca (1x ico51200, 1x ico58560DJ, 1x ico59920P, 1x ico58750C)
	icoK53025	ICON 2007+ Toyota Tundra 1-3in Stage 5 Suspension System w/Billet Uca (1x ico51200, 1x ico58560DJ, 1x ico57720P, 1x ico58750)
	icoK53026	ICON 2007+ Toyota Tundra 1-3in Stage 6 Suspension System w/Billet Uca (1x ico51200, 1x ico58560DJ, 1x ico57720CP, 1x ico58750C)

Data: v4.2 - Upd: 2026-10-22 07:37:16

Features

Specifications

Product Attributes - UPC

00840103403748

Product Attributes - Brand

ICON Vehicle Dynamics

Product Attributes - Quantity

Sold as a pair.

Product Attributes - Part Type

Control Arms

Product Attributes - Adjustable

Yes

Product Attributes - Product Line

Icon Vehicle Dynamics Delta Joint Billet Upper Control Arms

Product Attributes - Bushings Included

Yes

Product Attributes - Control Arm Color

Silver

Product Attributes - Control Arm Style

Billet

Product Attributes - Hardware Included

Yes

Product Attributes - Ball Joint Included

Yes

Product Attributes - Control Arm Material

Billet aluminum

Product Attributes - Manufacturer's Part Number

58560DJ

Compatibility
