Ford Racing 5.2L Gen 3 Coyote Aluminum Engine Block

SKU: FRPM-6010-M52B

Engines, Bare Blocks

FR Engine Blocks...

Ford Racing

Ford Racing 5.2L Gen 3 Coyote Aluminum Engine Block

SKU: FRPM-6010-M52B

Engines, Bare Blocks

FR Engine Blocks...

IN STOCK! Est Ship 4-7 days. This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.

We accept

Description

Ford Performance Parts 5.2L Gen 3 Coyote aluminum engine blocks are upgraded versions of the Gen 1 and Gen 2 blocks (M-6010-M52 and M-6010-M52A). They feature higher flow oil squirters to provide added piston cooling and improved crankcase windage. All features are finish-machined, including head deck and crank bore. Get revved up for the improved high performance casting of Ford Performance 5.2L Gen 3 Coyote aluminum engine blocks and their ability to support higher horsepower engine builds!

Features, items, and specs:

* 94.0mm bore
* Rod bolt path is clearance-machined in crankcase of block
* Utilizes longer (187mm) cylinder headbolts to provide greater clamping force (requires longer headbolt kit: M-6067-M501280 or M-6067-M52B head changing kit)
* Water jacket below cylinder bore updated to add more material for strength
* Intake side of bore at deck surface includes cast-in brace (improves strength of cylinder wall and head gasket sealing)
* Block features plasma-transferred wire arc spray weld liner coating (improved durability and heat transfer, reduced friction, and weight savings compared to previous Mustang GT aluminum blocks)
* Cylinder liner coating doesn't require unique piston rings or piston material
* Cylinder bores finish-honed and ready to assemble
* Cross-bolted nodular iron main bearing caps—uses 12mm cylinder head bolts
* Block has provisions for piston oil squirters (included)
* Plugs and dowels

Product Overview

Coyote Production Engine Block; Gen 3 5.2L Aluminum Cylinder Blocks; 94.0mm Bore; Incl. Plugs And Dowels And Oil Squirters;

Features and Benefits

Higher Flow Oil Squirters To Provide Added Piston Cooling
Rod Bolt Path Is Clearance Machined In Crancase Of Block
Improved Crankcase Windage
94.0mm Bore
Cylinder Bores Are Finish-Honed And Ready To Assemble
All Block Features Are Finish-Machined
Cross-Bolted Nodular Iron Main Bearing Caps
Uses 12mm Cylinder Head Bolts
Block Has Provisions For Piston Oil Squirters
Includes Plugs And Dowels And Oil Squirters
Rod Bolt Path Is Clearance Machined In Crankcase Of Block

Product Details

Description:	Coyote Production Engine Block
Part Number:	frpM-6010-M52B
Prop 65 Yes/No:	No
Title:	Ford Performance - 5.2L "Gen 3" Coyote Aluminum Engine Block - M-6010-M52B
WARNING CA Proposition 65:	No

Part Type

Aluminum Engine Block 5.2L Gen-3 Coyote

Data: v4.2 - Upd: 2026-10-22 02:07:25

Features

94.0mm Bore
All Block Features Are Finish-Machined
Block Has Provisions For Piston Oil Squirters
Cross-Bolted Nodular Iron Main Bearing Caps
Cylinder Bores Are Finish-Honed And Ready To Assemble
Higher Flow Oil Squirters To Provide Added Piston Cooling
Improved Crankcase Windage
Includes Plugs And Dowels And Oil Squirters
Rod Bolt Path Is Clearance Machined In Crancase Of Block
Rod Bolt Path Is Clearance Machined In Crankcase Of Block
Uses 12mm Cylinder Head Bolts

Specifications

Product Attributes - Brand: Ford Performance Parts
Product Attributes - Manufacturer's Part Number: M-6010-M52B
Product Attributes - Part Type: Engines, Bare Blocks
Product Attributes - Product Line: Ford Performance Parts 5.2L Gen 3 Coyote Aluminum Engine Blocks
Product Attributes - UPC: 756122012109
Product Attributes - Main Journal Type: Ford 5.0 Modular
Product Attributes - Engine Block Material: Aluminum
Product Attributes - Engine Block Style: OEM
Product Attributes - Engine Block Deck Height: Standard deck
Product Attributes - Cylinder Bore Diameter: 3.700 in.
Product Attributes - Camshaft Location: Standard
Product Attributes - Main Caps Included: No
Product Attributes - Main Cap Material: Nodular iron
Product Attributes - Main Cap Fasteners Included: No
Product Attributes - Main Bearings Included: No
Product Attributes - Rear Main Seal Style: 1-piece
Product Attributes - Finished Cylinder Bores: Yes
Product Attributes - Raised Cam Location: No
Product Attributes - Cam Bearings Included: No
Product Attributes - Freeze Plugs Included: No
Product Attributes - Remanufactured: No
Product Attributes - Quantity: Sold individually.

Reference Information

Brand Name/s	Ford Racing
StreetFX SKU	frpM-6010-M52B
SFX Item ID	4302721
Supplier Item Code	4302721
Manufacturer SKU	M-6010-M52B
Manufacturer UPC	756122012109
Alternative References	fms-m-6010-m52b, FRDM6010-M52B, 5.2L
