Eagle Chevrolet Small Block 5.700in Length 2.000in Rod Journal Forged Steel H-Beam Rods - Set of 8
Eagle Chevrolet Small Block 5.700in Length 2.000in Rod Journal Forged Steel H-Beam Rods - Set of 8
A$1,439.71
LOW STOCK! Est Ship 4-7 days.
HURRY! LOW STOCK. This item is in limited stock at one of our distribution centres. The ETA is the approximate time required to prepare your order for dispatch.
We accept
Description
Forged 4340 steel H-Beam connecting rods are forged from a two-piece forging and feature a fully machined and shot-peened surface. Sizing is held to exact tolerances. Sold as a weight-matched set. Recommended for competition use.
Application Summary
CHEVY SMALL BLOCK
Part Type
Engine Connecting Rod
Specifications
- Product Attributes - Brand
- Eagle Specialty Products
- Product Attributes - Manufacturer's Part Number
- CRS5700S3D
- Product Attributes - Part Type
- Connecting Rods
- Product Attributes - Product Line
- Eagle H-Beam Connecting Rods
- Product Attributes - UPC
- 793348033600
- Product Attributes - Connecting Rod Length Center to Center (in.)
- 5.700 in.
- Product Attributes - Connecting Rod Beam Style
- H-beam
- Product Attributes - Connecting Rod Material
- Forged 4340 steel
- Product Attributes - Wrist Pin Style
- Floating
- Product Attributes - Pin End Bore Diameter
- 0.927 in.
- Product Attributes - Rod Journal Diameter (in.)
- 2.000
- Product Attributes - Big End Bore Diameter (in.)
- 2.1250
- Product Attributes - Quantity
- Sold as a set of 8.
- Product Attributes - Cap Retention Style
- Cap screw
- Product Attributes - Big End Width (in.)
- 0.940
- Product Attributes - Clearanced for Stroker
- No
- Product Attributes - Connecting Rod Bolt Brand
- ARP
- Product Attributes - Connecting Rod Bolt Diameter
- 7/16 in.
- Product Attributes - Connecting Rod Bolt Material
- 8740 chromoly steel
- Product Attributes - Fastener Tensile Strength (psi)
- 180,000 psi
- Product Attributes - Connecting Rod Bolt Head Style
- 12-point
- Product Attributes - Approximate Connecting Rod Weight (g)
- 650
- Product Attributes - Advertised Horsepower Rating
- 800 hp
- Product Attributes - Pin End Width (in.)
- 1.060 in.
- Product Attributes - Weight Matched Set
- Yes
- Product Attributes - Remanufactured
- No
- Product Attributes - Magnafluxed
- Yes
- Product Attributes - Connecting Rod Color
- Shot-peened
- Product Attributes - Notes
- For small journal crankshafts.
Reference Information
| Brand Name/s | Eagle |
|---|---|
| StreetFX SKU | eagCRS5700S3D |
| SFX Item ID | 4059319 |
| Supplier Item Code | 4059319 |
| Manufacturer SKU | CRS5700S3D |
| Manufacturer UPC | 793348033600 |
| Alternative References | ESP-CRS5700S3D, 5.700in, 2.000in |
Compatibility
CHEVY SMALL BLOCK
