Bilstein 5160 Series 04-08 Ford F-150/06-08 Lincoln Mark LT Rear Shock Absorber
Bilstein 5160 Series 04-08 Ford F-150/06-08 Lincoln Mark LT Rear Shock Absorber
A$503.61
IN STOCK! Est Ship 3-5 days.
This item is IN STOCK at one of our warehouses or distribution centres, the ETA is the approximate time required to prepare your order for dispatch.
We accept
Description
Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUVs. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting and an attractive billet reservoir mount where applicable providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.
Product Overview
Bilstein B8 5160 remote reservoir shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. The remote reservoir will offer increased cooling capacity and wheel travel to optimize overall performance compared to a traditional shock absorber. These shock absorbers feature a monotube design for consistent fade free performance and utilize velocity sensitive digressive valve settings which are tuned for each specific application. Each shock absorber is fitted with a unique 360 degree swivel banjo hose fitting, providing a clean, low profile installation. B8 5160 remote reservoir shock absorbers will increase overall durability of your vehicle allowing you to conquer the harshest of off-road environments.
Features and Benefits
- Vehicle Specific Ride Tuning
- Remote reservoir increases shock oil capacity for greater heat dissipation
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control
Product Details
| Adjustable Damping: | Non-Adjustable |
|---|---|
| Billet Reservoir Clamp Included: | No |
| Body Design: | Smooth Body (Non-Coilover) |
| Body Diameter (ID): | 46mm |
| Body Inside Diameter: | 46mm |
| Boot Included: | No |
| Collapsed Length (IN): | 15.43 |
| Collapsed Length (MM): | 392 |
| Collapsed Length: | 392mm |
| Description: | B8 5160-Shock Absorber |
| Extended Length (IN): | 26.02 |
| Extended Length (MM): | 661 |
| Extended Length: | 661mm |
| Finish: | Zinc Plated |
| Internal Design: | Monotube |
| Lower Mount Type: | Eye 12mm |
| Optional Reservoir Clamp: | 11-176015 |
| Part Number: | bil25-255065 |
| PartType: | Shocks / Struts |
| Position: | Rear |
| Prop 65 (Y/N): | Y |
| Prop 65 - Short Label: | WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov |
| Reservoir Included: | Yes |
| Reservoir: | Yes |
| Segment: | Light Truck |
| Series: | B8 5160 |
| Spring Seat Included: | No |
| Title: | Bilstein Shock Absorbers |
| Upper Mount Type: | Eye 12mm |
| WARNING CA Proposition 65 Message: | WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov |
| WARNING CA Proposition 65: | Yes |
Application Summary
Ford F-150 2008-2004; Lincoln Mark LT 2008-2006
Part Type
Suspension Shock Absorber
Features
- 46mm monotube design ensures consistent, fade-free performance in all conditions
- Remote reservoir increases shock oil capacity for greater heat dissipation
- Self-adjusting deflective disc valving reacts immediately to surface changes enabling maximum vehicle control
- Vehicle Specific Ride Tuning
Specifications
- Adjustable Damping:
- Non-Adjustable
- Billet Reservoir Clamp Included:
- No
- Body Design:
- Smooth Body (Non-Coilover)
- Body Diameter (ID):
- 46mm
- Body Inside Diameter:
- 46mm
- Boot Included:
- No
- Collapsed Length (IN):
- 15.43
- Collapsed Length (MM):
- 392
- Collapsed Length:
- 392mm
- Description:
- B8 5160-Shock Absorber
- Extended Length (IN):
- 26.02
- Extended Length (MM):
- 661
- Extended Length:
- 661mm
- Finish:
- Zinc Plated
- Internal Design:
- Monotube
- Lower Mount Type:
- Eye 12mm
- Optional Reservoir Clamp:
- 11-176015
- Part Number:
- bil25-255065
- PartType:
- Shocks / Struts
- Position:
- Rear
- Prop 65 (Y/N):
- Y
- Prop 65 - Short Label:
- WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
- Reservoir Included:
- Yes
- Reservoir:
- Yes
- Segment:
- Light Truck
- Series:
- B8 5160
- Spring Seat Included:
- No
- Title:
- Bilstein Shock Absorbers
- Upper Mount Type:
- Eye 12mm
- WARNING CA Proposition 65 Message:
- WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov
- WARNING CA Proposition 65:
- Yes
Reference Information
| Brand Name/s | Bilstein |
|---|---|
| StreetFX SKU | bil25-255065 |
| SFX Item ID | 4438052 |
| Supplier Item Code | 4438052 |
| Manufacturer SKU | 25-255065 |
| Manufacturer UPC | 651860773582 |
| Alternative References | bsn-25-255065, F-150/06-08 |
Compatibility
Ford F-150 2008-2004; Lincoln Mark LT 2008-2006
